技术参数、

1.供电：三相五线制AC380V±10％，频率50Hz±5％.

2.输入额定电流：400A ,

3.额定功率：96路X4KW

4.设有总开关,过载与短路双重保护高分断空气开关.

5.三相独立电压，电流，监测，三相A.B.C 指示灯指示.

6.输出功率：96路X4KW/6KW

7.输出方式：40A胶木插

8.外形尺寸（mm）:600*600*1100 22U

9.产品重量：65KG
